How KYN28-12 Switchgear Receives, Distributes, Controls, Protects & Monitors Power

The KYN28‑12 metal‑clad withdrawable AC metal‑enclosed switchgear (medium‑voltage cabinet) is core complete‑set equipment for 12 kV indoor power distribution. Manufactured in compliance with IEC 62271‑200 and GB/T 3906, it is widely applied in substations, industrial‑mining projects, photovoltaic power plants, urban power‑grid renovation and overseas infrastructure.So how does the KYN28-12 switchgear accept, distribute electric power, and achieve circuit control, protection, and monitoring?

This switchgear receives high‑voltage power via incoming‑feed units, distributes energy through busbar systems, controls circuits by vacuum‑circuit‑breaker trucks, implements fault protection with microprocessor‑based relays, and conducts operational monitoring using CTs, PTs and secondary instruments. Integrating these five key functions, it serves as a critical hub for 10‑12 kV power‑distribution systems.Zhejiang Deyan Electric Co., Ltd. is located in Leqing, Wenzhou, Zhejiang. It specializes in the R&D, production and export of high and low voltage complete set of distribution equipment. It can provide standardized and customized KYN28-12 switchgear comprehensive solutions, with products suitable for project conditions in multiple overseas countries in Asia, Africa, Latin America, the Middle East and other regions.

1. Power Reception: Inlet for High‑voltage Supply

Power reception is mainly completed by the incoming‑feed cabinet. 12 kV high‑voltage power from upstream substations or transformers is fed into the cable compartment of the incoming‑feed cabinet via cables or bus ducts, then connected to the main busbars inside the busbar compartment.

Adopting a metal‑partitioned compartmentalized structure, the busbar compartment, circuit‑breaker compartment, cable compartment and secondary‑instrument compartment are separated by metal barriers. This mitigates arc‑fault risks and ensures safe and stable high‑voltage power intake. KYN28‑12 switchgears manufactured by Zhejiang Deyan Electric are compatible with 50 Hz/60 Hz power grids and support various rated current specifications. Customization for high‑altitude, high‑temperature and dusty environments is available to suit grid operating conditions in Southeast Asia, Africa, Latin America and other overseas countries.

2. Power Distribution: Power Delivery to Multiple Load Circuits

After power reaches the main busbars, power distribution is realized through outgoing‑feed cabinets, bus‑coupler cabinets and PT metering cabinets. The main busbars divert electric energy to individual outgoing circuits for downstream loads such as distribution transformers, high‑voltage motors, photovoltaic grid‑connected devices and mining equipment.

Single‑busbar and sectionalized single‑busbar configurations are supported. Additional outgoing‑feed cabinets can be added to expand capacity for industrial parks, mines and new‑energy power stations, enabling rational power allocation and improved power‑supply reliability. Zhejiang Deyan Electric can complete complete‑set cabinet solution design, assembly and full‑scope factory tests in accordance with customers' single‑line diagrams, so as to reduce the pressure of on‑site commissioning for overseas projects.

3. Circuit Control: Circuit Switching via Circuit‑breaker Truck

The vacuum‑circuit‑breaker truck is the core control component of KYN28‑12. It has three positions:

• Service position: Primary circuit closed for normal power supply;
• Test position: Primary circuit isolated while secondary control circuits remain energized for debugging without high voltage;
• Removed position: Truck fully extracted for complete galvanic isolation to facilitate maintenance and replacement.

Both local manual operation and remote electric closing/tripping are available for circuit switching and load transfer. A complete mechanical "five‑prevention" interlock system prevents mal‑operations such as truck insertion/withdrawal under load or door‑opening on live compartments, eliminating safety hazards caused by operator error. Deyan Electric conducts full‑item verification of mechanical interlocks prior to factory delivery to ensure safe and reliable on‑site operation.

4. Circuit Protection: Multi‑level Fault Mitigation for Fault‑circuit Isolation

Mechanical interlocks and intelligent control systems coordinate with vacuum circuit breakers to handle common distribution faults including short‑circuit, overload, earth‑fault and abnormal voltage:

• Instantaneous short‑circuit protection: Trips within milliseconds upon short‑circuit occurrence to isolate faulty circuits and restrain fault propagation;
• Overload protection: Delayed tripping under sustained overload to avoid overheating damage to cables and equipment;
• Earth‑fault protection: Detects single‑phase earth faults and triggers tripping or alarms against leakage risks;
• Over‑voltage / under‑voltage protection: Monitors busbar voltage via PTs and cuts off power when voltage exceeds thresholds, suitable for overseas grids with severe voltage fluctuation.

The compartmentalized metal‑clad design confines internal arcs within a single compartment, preventing single‑point faults from spreading to the whole busbar and maintaining power supply for healthy circuits. Mainstream domestic and international protection relays can be configured to satisfy technical specifications of different countries.

5. Circuit Monitoring: Real‑time Data Acquisition for Intelligent Operation & Maintenance

Circuit monitoring is implemented cooperatively by current transformers (CTs), voltage transformers (PTs), smart meters, live‑line indicators and protection units. CTs collect circuit current while PTs acquire busbar voltage. Operational data are transmitted to secondary instruments and protection devices. Operators can read real‑time parameters including voltage, current, power and circuit‑breaker status; the system records fault events and outputs alarm signals. Live‑line indicators give clear visual warnings of energized high‑voltage compartments. Certain configurations support SCADA connection for remote data access and status monitoring, lowering on‑site O&M workload for overseas projects. Deyan Electric can supply complete secondary schematic diagrams and wiring drawings as supporting documents to facilitate construction coordination for overseas EPC engineers.

6. Advantages for Foreign‑trade Projects

• Environmental adaptability: Standard operating temperature range: ‑15 ℃ ~ +40 ℃; derated custom designs for high‑altitude, high‑temperature, humid and dusty environments.
• Compliance & certification: Manufactured to IEC 62271 international standards. CE, ISO 9001 and other certificates are available for project acceptance and customs clearance.
• Modular construction: Cabinet assembled from galvanized‑aluminum steel sheets processed by CNC. Simple installation; modular trucks ease spare‑part replacement and reduce maintenance costs.
• One‑stop service: Scope covers solution design, manufacturing, factory tests, sea‑worthy packaging and technical‑document delivery. OEM / ODM customization is supported. Protection class, circuit configuration and 50 Hz / 60 Hz frequency can be tailored as required.

Summary

KYN28‑12 switchgear receives electric energy via incoming‑feed units and distributes power through busbar systems. Vacuum‑circuit‑breaker trucks perform circuit control; microprocessor‑based protection relays realize fault protection; CTs, PTs and secondary intelligent components enable circuit monitoring. The coordination of these five functions guarantees safe and reliable operation of 12 kV power‑distribution systems.As an original equipment manufacturer, Zhejiang Deyan Electric Co., Ltd. can provide overseas EPCs and engineering contractors with complete customized and supply services for KYN28-12 switchgear, serving as a reliable partner for overseas medium-voltage distribution projects.
